14-Inch (355.6 mm) Drill-Center Pulls: Spec, Measurement, and Sizing Context
Understanding the 14-Inch Drill-Center Specification
The 14-inch drill-center measurement refers to the center-to-center distance between the two screw holes that mount a pull to a cabinet surface — not the overall bar length, which is typically longer than the drill-center span, depending on the manufacturer. Converting to metric: 14 × 25.4 = 355.6 mm exactly. Any reference to 356 mm is a rounded approximation; 355.6 mm is the precise figure and the value hardware suppliers use in technical specifications. To measure an existing pull for replacement, hold a ruler from the center of one screw hole to the center of the other. On a pull already mounted to a door or drawer, that measurement should read 14 inches (355.6 mm) to confirm compatibility. If the existing holes cannot be measured directly, measure between the two holes on the cabinet face itself — this is the drill-center dimension the replacement pull must match. A 14-inch drill-center suits drawer fronts and door panels generally in the range of 18 inches wide or greater, where the pull occupies a proportional share of the face without crowding the edges. It appears frequently on tall pantry doors and full-height appliance panels where a single long pull is preferred over stacked shorter hardware.
Construction, Adjacent Sizes, and Sizing Decisions
At this drill-center length, bar and T-bar profiles in solid construction are the predominant form factor. The extended span places meaningful torque on the mounting points, and through-bolt construction is common in this size range for that reason, distributing load across the full thickness of the panel rather than relying on wood threads alone. For narrower applications, the adjacent smaller size is 12 inches (304.8 mm). For wider panels, the next standard steps are 16 inches (406.4 mm) and 18 inches (457.2 mm). Sizing down from 14 inches is appropriate when the drawer or door front is narrower and the pull would otherwise extend too close to the edges; sizing up suits wider panels where 14 inches reads as visually undersized relative to the face. **FAQ** *What does 14-inch drill-center mean?* The distance between the centers of the two mounting screw holes, measured in a straight line: 14 inches, or 355.6 mm exactly. *Is 355.6 mm the same as 356 mm?* 355.6 mm is the precise conversion of 14 inches (14 × 25.4). The value 356 mm is a rounded approximation sometimes used in catalog shorthand. *How do I measure my existing screw-hole spacing?* Measure from the center of one hole to the center of the other on the cabinet face or on the pull itself. *What cabinet widths suit a 14-inch drill-center pull?* The size is generally appropriate for door and drawer fronts roughly 18 inches wide or greater, though proportion and design intent determine the final choice.
Browse all cabinet pulls or see the cabinet hardware sizing guide.
Frequently Asked Questions
What is 14 inches in millimeters for a cabinet pull drill-center?
A 14 inch drill-center converts to 355.6 mm (14 x 25.4 mm). Drill-center is the distance from the center of one mounting screw hole to the center of the other, not the overall length of the pull. To confirm an existing setup, measure between the centers of the two screw holes on the back of the door or panel.
How do I measure the drill-center on an existing pull to confirm it's 14 inch?
Measure from the center of one mounting hole to the center of the other mounting hole; that center-to-center figure is the drill-center, and 14 inch corresponds to 355.6 mm. Measuring hole-center to hole-center (rather than the pull's full length) ensures a replacement lines up with holes already drilled in the panel. If the measurement falls between sizes, match the existing screw holes rather than the pull's overall length so no new holes are needed.
What cabinet and appliance fronts is a 14 inch (355.6 mm) drill-center pull suited for?
The 355.6 mm spacing is common on column refrigerator drawer fronts, full-height freezer drawers, oversized panel-ready dishwashers, and tall pantry doors in custom kitchens. Column-style refrigeration is the largest single user of this size, with integrated columns from brands such as Sub-Zero, Thermador, and Miele often specifying 14 inch as the panel pull length. Built-in wine columns and dual-zone refrigeration also use 14 inch as a standard panel pull length.
How does the 14 inch (355.6 mm) size compare to 12 inch and 16 inch drill-centers?
For narrower fronts, 12 inch (304.8 mm) is the size to step down to, while wider applications step up to 16 inch (406.4 mm) or 18 inch (457.2 mm). The 14 inch length sits in dedicated appliance pull territory and carries real architectural weight on a cabinet face. On a refrigerator-freezer column install, the common practice is holding 14 inch consistently on both units rather than mixing sizes, since most appliance pull families produce 14 inch as the default column-pair length.
